Opis
Specs:
1.Firmware:5.2, supports firmware upgrade
2.Voltage: 14-84V (safe for 4-20S)
3.Continuous Current: 50V/200A; 75V/150A (Values depend on the mounting, ambient temperature and air/water circulation around the device!); Burst: 300A
4.BEC:5V@1A
5.Support Modes:DC, BLDC, FOC (sinusoidal)
6.ERPM:150000
7.Communication Ports:USB, CAN, UART, SPI, IIC
8.Supported Sensors:ABI, HALL, AS5047, AS5048A
9.Input Source Support:PPM, ADC, NRF, UART
10.Supported Sensorless:Yes
11.Regenerative Capacity:Yes
12.Programmable via VESC_TOOL:Yes
13.Size:130×67.7×40.1mm(Including alu. case)
14.Motor/Power Wire Size:8 AWG
15:Online Manual Download
Features:
1.Adjustable protection against: low voltage protection, high voltage protection, over current protection, temperature abnormal protection, mosfets / motor over temperature protection.
2.Support various control modes: Current / Duty cycle / Speed / PID control modes.
3.Support the function of balancing car by connecting the IMU module through the IIC interface; support inertial measurement unit modules such as MPU9250, MPU9150, MPU6050, LSM6DS3, BMI160.
4.CPU:STM32F405 with frequency 168MHz
5.Aluminum PCB with good heat dissipation to expand life span.
6.Two COMM ports: UART bluetooth module, screen display or remote controller supportable.
Package Included:
1X ESC 75200
